Research on thermal runaway characteristics and early warning methods of lead-acid batteries
Liu Bingxi, Xie Fei, Zhang Jin, Zhuo Ping, Ma Xiao, Bi Xiaoyang
2025, 44 (9):
1233-1238.
An experimental platform integrating constant-temperature environment simulation, charge-discharge control, and multi-parameter monitoring (temperature, voltage, gas concentration) was established. Normal charge-discharge and overcharge comparison tests were conducted under three environmental temperatures. The study found that during normal charge-discharge, the temperature change of the battery is dominated by the environmental temperature, with a slow temperature rise at low temperatures, a continuous temperature increase at high temperatures, and a stable temperature at room temperature. Under the overcharge condition, however, significant dangerous characteristics were observed: the battery temperature exceeded 100 °C in all three environmental temperatures, accompanied by the intense release of flammable gases such as hydrogen, VOCs, sulfur dioxide, and hydrogen sulfide, posing an explosion risk in a confined space, with the fastest temperature rise rate at 40 °C. Based on these findings, this paper proposes an intelligent thermal runaway early warning system: relying on the BMS master-slave architecture, it collects battery terminal voltage, multi-point temperatures, and hydrogen/VOCs gas concentrations in real time. The core early warning parameters include temperature thresholds, upper limits of temperature rise rate, and hydrogen concentration thresholds, and it integrates SOC/SOH algorithms to track the battery's health status. This system can respond to abnormal temperature rise and gas leakage within milliseconds, triggering protection mechanisms to prevent thermal runaway accidents.
